Furuno FCV1150 12.1" Color Fish Finder – High-Resolution Marine

Overview

Unlock professional fish-finding power with the Furuno FCV1150 (model 010-1150-00), a high-performance 12.1″ color marine fish finder designed for serious anglers, trolling, and commercial fishing operations.

Engineered for dependable operation in harsh marine environments, this advanced sonar unit delivers precise underwater imaging with adjustable frequency and powerful transmission to locate fish faster.

Ideal for deep-sea, fleet, or recreational applications, the FCV1150 is compatible with a wide range of Furuno transducers and multifunction display systems.

Key Features

• High-resolution 12.1″ color LCD (800×600 px) with anti-reflective AR glass and anti-polarized sunglass filter for superior visibility in bright sunlight.
• Furuno Free Synthesizer (FFS) Technology for flexible frequency selection (28–200 kHz) enabling precise target separation and reduced interference.
• Selectable power output (1, 2, 3 kW) with advanced transmission automatically adjusting for shallow or deep water detection.
• Multiple display modes: Single (HF/LF), Dual, Single + Zoom, Bottom Lock / Marker Zoom, Mix Mode, A-Scope, NAV data, plus two programmable custom modes.
• White Edge seabed discrimination and Furuno Digital Filter (FDF) provide clear separation between bottom terrain and fish targets.
• Heaving compensation (requires Furuno Satellite Compass) stabilizes echo presentation in rough seas.
• Easy gain adjustment via rotary knob and post-processing control for instant visibility optimization.
• IP55 waterproof rating protects the flush-mounted display from water spray, salt, and harsh marine conditions.
• NavNet® compatible via Ethernet for integrated multifunction display control (auto range, gain, shift, zoom).
• Flexible power options: 12–24 VDC (3.3–1.7 A) or 100/110/220/230 VAC with optional rectifier.

Applications

• Recreational and commercial fishing, trolling, and fleet operations.
• Powerfully images fish and bottom terrain in shallow, mid, and deep water.
• Compatible with Furuno multifunction displays and Ethernet NavNet® systems.
• Ideal for serious anglers, commercial operators, and marine enthusiasts seeking high-precision sonar.

What’s Included

• FCV1150 display unit (transducer not included)
• Protective cover
• Mounting bracket & installation hardware
• 2 control knobs & 4 fuses
• Recess cut-out template
• Installation joint & kit
• Cleaning cloth
• Installation Manual, User Manual & Quick Reference Guide
• Backed by Furuno USA 2-year parts & labor warranty (installed per instructions, warranty start ≤18 months from original dealer purchase)

Specifications

• Display Size: 12.1″ (800×600 px) color LCD
• Housing Dimensions: 345×356×199 mm, ~8.2 kg (bracket mount)
• Power Output: 1/2/3 kW selectable
• Frequency Range: 28–200 kHz (FFS Technology)
• IP Rating: IP55 (waterproof)
• Gain: Adjustable rotary knob + post-processing
• Compatible with Furuno NavNet® Ethernet systems
• Mounting: Flush
• Display Modes: Single, Dual, Mix, Bottom Lock, Marker Zoom, A-Scope, NAV, 2 custom modes
• Heaving Compensation: Supported (with Furuno Satellite Compass)
• Power Requirements: 12–24 VDC (3.3–1.7 A) or optional 100/110/220/230 VAC rectifier

Notes & Warranty

• Transducer not included; select compatible Furuno transducers to match your fishing style and depth requirements.
• This product may not be returned to the original point of purchase; contact the manufacturer for issues or concerns.
• Covered by Furuno USA 2-year warranty on parts and labor if installed per instructions.
