![Suncoast Marine and Auto offers Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A [7042]](http://www.suncoastmarineandauto.com/cdn/shop/files/20527XL.jpg?v=1737754824&width=1946)
Blue Sea Systems
Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A [7042]
Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A [7042]
Couldn't load pickup availability
Shipping
Shipping
FREE
- Standard Shipping on Orders over $99
- 2-Day Shipping on Orders over $699
Low Cost Options
- $9.99 Standard Shipping on Orders under $99
- $19.99 2-Day Shipping on orders under $699
Special Deliveries
- Truck Freight and Hazardous items vary and may take 5-7 business days.
Tracking
- Tracking numbers and all other information regarding your order is sent via email automatically once available. (Contact us for specific inquiries)
Read our Shipping Policy
(restrictions may apply to these terms)
Delivery Times
Delivery Times
Handling Times
- Orders ship within 24 hours of purchase. (Next Day Shipping Available)
Delivery Times
- All Orders typically take 3-5 business days to arrive. (unless noted otherwise in the Product's Description)
- Choose 2-Day Shipping at Checkout to receive a Priority Delivery Experience. (available on select orders)
- "Made-to-order" items, Truck Freight or Hazardous items may take 5-7 business days.
- Always check with a Team Member if you have questions about a specific delivery time.
See our Shipping Policy for more information.
(restrictions may apply to these terms)
Returns and Refunds
Returns and Refunds
- Suncoast honors a 30-day return policy for unused items in their original packaging with proof of purchase.
- If your item doesn't meet your expectations, please contact us to initiate a return or exchange.
- Certain items, like installed products and special orders, cannot be returned.
- Refunds are processed within 10 business days after approval, payment processing fees are non-refundable.
For more details and restrictions, please read our Refund Policy.
(restrictions may apply to these terms)
Check Availability
Check Availability
Not sure if this item is in stock?
- Live Chat with the Owner below.
- Receive a response within a few minutes regarding availability, pricing, product details or questions, etc.
Feel free to Call or Text us or Email us for any cancellation requests, questions or updates on your order or view more Contact Information.
![Suncoast Marine and Auto offers Blue Sea 7042 187-Series Circuit Breaker - Panel Mount 80A [7042]](http://www.suncoastmarineandauto.com/cdn/shop/files/20527XL.jpg?v=1737754824&width=1445)
Product Description
7042 187-Series Circuit Breaker - Panel Mount 80A
Features:
- Combines switching and circuit protection into a single device*
- Precise, single-lever operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Ample Clearance around terminal studs accepts heavy gauge wire lugs
- Robust 5/16 M8 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition-protected - Safe for installation aboard gasoline powered boats
Specifications:
- Amperage: 80A
- Maximum Voltage: 48V DC
- Mounting: Panel Mount
- Circuit Breaker Type: Thermally responsive Bi-metal blade
- Terminal Stud Torque: 75 in-lb (8.47 Nm)
- Interrupt Capacity: 5000A @ 14VDC, 3000A @ 28VDC, 1500A @ 48VDC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Case Material: Thermoset Polyester
- Circuit Breaker Class: Type III - switchable/manual reset - trip-free
- Mounting Hole: Accept #10 (M5) Screw
- Terminal Stud Size: 5/16" - 18
- Weight: 0.5lb (0.23 kg)
- Weight: 0.50lb (0.23 kg)
* Do not use as a switch where high inrush currents are expected.
Specifications:
- Amperage: 80a
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
